Partial Inductance

Posted on Edited on In

Loop Inductance is the sum of partial self-inductance and partial-mutual inductance

Magnetic Vector Potential (磁矢势)

Youjin Deng. 5-3 静磁场的基本规律 [http://staff.ustc.edu.cn/~yjdeng/EM2022/pdf/5-2(2022).pdf]

磁场不能用标量势描述

image-20250709195107708

image-20250709195217587

image-20250709200229266

image-20250708231822291

Partial Inductance

image-20250708230643776

self partial inductance

image-20250708233924675

mutual partial inductance

image-20250708234512418

Ex. two-wire

image-20250709001127400

image-20250602120913866


[https://www.oldfriend.url.tw/Q3D/ansys_ch_Partial_Loop_Inductance.html]

Current Return Path

image-20250705171613361

Current return paths are frequency dependent \(Z = R +j\omega L\)

  • Low frequency
    • \(R\) dominates - current use as many returns as possible to have parallel resistances
  • High frequency
    • \(j\omega L\)​ dominates - current use the closest possible return path to form the smallest possible loop inductance
  • Very high frequency
    • The current would be confined to the nearest possible return only at ultra-high frequencies (skin effect)

image-20250705170949035

image-20250705170028485

EMX simulation

setup:

image-20250706004037966

frequency sweep:

image-20250706010943996

Cadence October 2020, Analysis of a Figure-Eight Inductor with EMX RAK

image-20250706010216105

proximity effect & skin effect

  • Skin effect concentrates current near the surface of a single conductor, while proximity effect concentrates current in specific regions of multiple conductors due to their interaction
  • Skin effect is caused by the conductor's own magnetic field, while proximity effect is caused by the magnetic field of a nearby conductor

proximity effect is a redistribution of electric current occurring in nearby parallel electrical conductors carrying alternating current (AC), caused by magnetic effects (eddy currents)

image-20250705163405433

skin effect is the tendency of AC current flow near the surface (or "skin") of a conductor, rather than throughout its cross-section, due to the magnetic field generated by the current itself

image-20250705165353751

Cause of skin effect

A main current \(I\) flowing through a conductor induces a magnetic field \(H\). If the current increases, as in this figure, the resulting increase in \(H\) induces separate, circulating eddy currents \(I_W\) which partially cancel the current flow in the center and reinforce it near the skin

Eddy current

By Lenz's law, an eddy current creates a magnetic field that opposes the change in the magnetic field that created it, and thus eddy currents react back on the source of the magnetic field

Electromagnetic coupling

Electric field coupling (also called capacitive coupling) occurs when energy is coupled from one circuit to another through an electric field

Two circuits above a signal return plane.

Magnetic field coupling (also called inductive coupling) occurs when energy is coupled from one circuit to another through a magnetic field

Two circuits above a signal return plane

For instance

  • magnetic coupling between multiple inductors
  • capacitive coupling between multiple transmission lines

Grounding

TODO 📅

Chapter 11 Layout and grounding [http://ieb-srv1.upc.es/gieb/tecniques/doc/EMC/pdfs/ScienceDirect_articles_27Jul2018_12-16-10.699/Chapter-11---Layout-and-grounding_2007_EMC-for-Product-Designers.pdf]

Decoupling Capacitor

image-20250705175343498

reference

ISSCC2002. Special Topic Evening Discussion Sessions SE1: Inductance: Implications and Solutions for High-Speed Digital Circuits [vSE1_Blaauw], [vSE1_Gauthier], [vSE1_Morton, [vSE1_Restle]]

Y. Massoud and Y. Ismail, "Gasping the impact of on-chip inductance," in IEEE Circuits and Devices Magazine, vol. 17, no. 4, pp. 14-21, July 2001 [https://sci-hub.se/10.1109/101.950046]

Clayton R. Paul, Partial Inductance [https://ewh.ieee.org/soc/emcs/acstrial/newsletters/summer10/PP_PartialInductance.pdf]

Cheung-Wei Lam. Common Misconceptions about Inductance & Current Return Path [https://ewh.ieee.org/r6/scv/emc/archive/022010Lam.pdf]

Randy Wolff. Signal Loop Inductance in [Pin] and [Package Model] [https://ibis.org/summits/feb10/wolff.pdf]

ANSYS Q3D Getting Started LE05. Module 5: Q3D Inductance Matrix Reduction [https://innovationspace.ansys.com/courses/wp-content/uploads/sites/5/2021/07/Q3D_GS_2020R1_EN_LE05_Ind_Matrix.pdf]

Paul, Clayton R. Inductance: Loop and Partial. Hoboken, N.J. : [Piscataway, N.J.]: Wiley ; IEEE, 2010.

Spartaco Caniggia. Signal Integrity and Radiated Emission of High‐Speed Digital Systems. Wiley 2008

Yuriy Shlepnev. How Interconnects Work: Characteristic Impedance and Reflections [https://www.linkedin.com/pulse/how-interconnects-work-characteristic-impedance-yuriy-shlepnev/]

-. How Interconnects Work: Bandwidth for Modeling and Measurements [https://www.linkedin.com/pulse/how-interconnects-work-bandwidth-modeling-yuriy-shlepnev/?trackingId=874kpm3XuNyV9D0eP6IioA%3D%3D]

Eric Bogatin. Pop Quiz: When is an Interconnect Not a Transmission Line? [https://www.signalintegrityjournal.com/blogs/4-eric-bogatin-signal-integrity-journal-technical-editor/post/265-pop-quiz-when-is-an-interconnect-not-a-transmission-line]

TeledyneLeCroy/SignalIntegrity Python tools for signal integrity applications [SignalIntegrityApp]

A Look at Transmission-Line Losses [http://blog.teledynelecroy.com/2018/06/a-look-at-transmission-line-losses.html]

How Much Transmission-Line Loss is Too Much? [http://blog.teledynelecroy.com/2018/06/how-much-transmission-line-loss-is-too.html]

Raymond Y. Chen, Raymond Y. Chen. Fundamentals of S Fundamentals of S-Parameter Parameter Modeling for Power Distribution Modeling for Power Distribution System (PDS) and SSO Analysis System (PDS) and SSO Analysis [https://ibis.org/summits/jun05/chen.pdf]
